Qmini Miniature Industrial Grade Spectrometer

With an amazingly small design, the Qmini delivers technical specifications that are unprecedented at this size. Its compact design enables tight integration in applications where space is limited, like mobile analysis devices.

The Qmini includes a powerful electronics board that enables:

• Full processing of spectra in the device (offset, nonlinearity, dark
spectrum, and spectral sensitivity)
• Averaging and smoothing
• Binning and buffering of spectra

Main Features:

• Miniature design
• Wavelength configurations between 190 nm and 1100 nm
• Replaceable entrance slit
• 2500 pixel linear sensor
• Integration time: 3 µs
• Operating temperature: – 15°C to 60 °C
• 30 pin auxiliary port
• Serial Interfaces: USB, SPI, UART
• Exceptional thermal stability of typ. < 0.003 nm/°C
• Free spectrometer software and spectrometer Software Development Kit
• Low power consumption

Specifications Table

• Agricultural measurements
• Biomedical applications
• Chemical research
• Color measurements
• Counterfeit detection
• Environmental analysis
• Forensic analysis
• Health and life science
• Light measurements
• Process control and monitoring
• Quality control
• Raman spectroscopy
• Water quality analysis
