From deep UV up to short-range near infrared absorptions measurements, the Broadcom Qwave is a compact industrial grade spectrometer combining high optical resolution, high dynamic range and high sensitivity that fits into the palm of a hand. The three standard wavelength configurations cover spectral ranges from 220 nm to 1030 nm, and spectral shifts down to a deep UV spectrometer module are possible.
Armed with a high-resolution 3648-pixel linear CCD detector, the Qwave 2 series can cope with much bulkier spectrometer designs, still maintaining a package size of 89.5 mm × 68.0 mm × 19.5 mm. Together with the smart spectrometer software Waves and various communication interfaces, the Qwave is the ideal spectroscopic instrument to be integrated into high performance applications.
Main Features
| Part Number | Product Configuration | Wavelength Range | Spectral Resolution |
|---|---|---|---|
| AFBR-S20W2UV | Qwave UV | 220 nm to 390 nm | 0.3 nm |
| AFBR-S20W2VI | Qwave VIS | 350 nm to 880 nm | 0.6 nm |
| AFBR-S20W2NI | Qwave NIR | 700 nm to 1030 nm | 0.5 nm |
Specs Table
| Specifications | |
|---|---|
| Focal Length | 75 mm |
| Grating | 600 lines/mm |
| Entrance slit | 20 μm (changeable) |
| Dynamic range | 1500:1 |
| Numerical aperture | 0.10 |
| Stray light | <0.1% |
| Exposure time range | 3 μs to 17 min. |
| Detector | 3648-pixel linear CCD detector |
| A/D converter | 16-bit |
| Calibration | Wavelength, sensitivity, nonlinearity, and multiple dark spectra stored within device |
| Internal memory | 32 MB (>3000 spectra) |
| Transfer speed to PC | USB 2.0 high-speed |
| Optical interface | SMA connector |
| Digital interfaces | USB 2.0 with Type-C connector, SPI, UART |
| Dimensions | 89.5 mm × 68.0 mm × 19.5 mm |
| Weight | 155g |
| Operating temperature | −15°C to 60°C (non-condensing) |
| Storage temperature | −25°C to 70°C |
| Power consumption | 5V DC, 200 mA (supplied via USB) |
| PC operating system | Windows 10, 8, 7, Vista, XP |
Light analysis
Chemical research
Raman spectroscopy
Forensic analysis
System integration
Process control and monitoring
Biomedical applications
Quality control
Environmental measurements
