APE WaveScan Spectrometers laser spectrum analysers cover a wide wavelength range from 200nm to 6300nm at high resolution. Especially at wavelengths beyond 1100nm, users benefit from the highest resolution at a low cost. The quick and easy exchangeable input port adapts the waveScan to free-space or fiber lasers. The software offers useful analytical tools and of course data export.
The WaveScan spectrometer is a compact and cost-efficient optical spectrometer to characterize light sources, e.g. ultrafast as well as cw laser systems. The rotating grating technology achieves high resolution at fair scan rates. This makes waveScan an ideal real-time alignment tool for laser systems.
Different configurations, from 200 nm UV to 6.3 µm in the mid-infrared range, make waveScan the choice for analyzing the spectrum of different laser types
WaveScan is available with an interchangeable fiber input in addition to a free-space input. Whether you need fast scan rates for adjustment or high resolution, combined with convenient measurement control and data processing – waveScan is the ideal solution.
Specifications
| waveScan | UV | Blue | VIS + IR | Extended IR | MIR |
|---|---|---|---|---|---|
| Wavelength range | 200nm-1100nm | 220nm-540nm | 500nm-1600nm | 800nm-2600nm | 1500nm-6300nm |
| Resolution (FWHM) | 0.2nm | 0.05nm | 0.2nm | 0.5nm | 3nm |
| Dynamic range | 3277 | 819 | 328 | ||
| Scan rate | ~5Hz | ||||
| Laser repetition rates | >4 MHz – real-time measurements >100 kHz – accumulation mode >100 Hz – triggered mode |
||||
| Input polarization | Optimized for horizontal polarization (also any other polarization possible) | ||||
| Beam input | Free-space per default Fiber coupling (FC/PC, SMA or FC/APC) optional | ||||
| Trigger Input | 100 Hz-100 kHz, BNC connection: 0.2 V to 5 V TTL signal, or photodiode signal (25 ns rise time) |
||||
| Connectivity | USB, TCP/IP (SCPI command set) | ||||
| Remote control | Programmable via API | ||||
