primoScan DPSS – High Repetition Rate Tunable OPO

The primoScan offers an extremely wide tunability from the UV to the mid-infrared spectral range and comes with innovative ultra-low divergence technology for best beam quality, narrow linewidth, and high efficiency.

The DPSS version of the primoScan series uses a soft pumping scheme with low fluence, ensuring maximum reliability.

Main Features:

• 190 – 2750 nm tuning range
• Ultra-low divergence
• Linewidth 3.5 cm-1 – 6 cm-1
• Single output port
• Fully automated for hands-free operation
• Fast shot-to-shot wavelength switching with < 100 ms shifting time
• Soft pumping scheme for high reliability and maximum lifetime

• Compact and robust DPSS-based pump laser
• Pump laser Diode warranty 5 billion shots
• Quick-connect cables and cooling lines.
• Temperature-controlled, plug-and-play harmonics with automatic phase-matching.
• Programmable OPO scans
• Common OPO outport for all wavelengths available
• Access to fundamental YAG harmonics
• All options, including UV generation, are integrated into a single box without manual reconfiguration.
• Pump laser and OPO computer controlled via USB connection.
• Control software/software development kit (SDK) included. OPO remote control using National Instruments LabView.
• OPO comes with a 2-year warranty. Optics are guaranteed for 3 months

Material Analysis
Multiphoton interactions
Medical applications
Laser Induced Fluorescence (LIF)
Combustion analysis
Remote sensing
Biotechnology
